Compact Remote Controller with Basic Functionality

• Up to 16 indoor units can be controlled with one remote controller.
• Suitable for hotels or offices as it is easily operated with no complex functions.
• Simple design that matches stylish interiors
• Large LCD screen and easy-to-use control buttons
• Backlight: White backlight makes it easy to operate in the dark.
• Nonpolar 2-core type

Vertical louver control:

Adjusts the vertical airflow direction of a duct-type indoor unit with an auto louver or a cassette type installed in a hotel room or a conference room.

Setting temperature range limitation:

Enables an indoor unit to operate in an energy-saving manner in a small building not equipped with a central remote controller.

Built-in room temperature sensor:

Monitors and controls room temperature accuracy.

1.

Room temperature sensor

Clearly indicates refrigerant leak

In the event of a refrigerant leak, the following actions will clearly notify the user:

• A buzzer will sound
• The backlight and operation indicator lamp will flash

*1

The necessity of a refrigerant leak detector varies depending on room conditions. For details, please refer to the Design & Technical Manual.

Notify when it’s time to replace the detector

One year before the refrigerant leak detector needs replacement, it will notify the user with the following actions:

• Display a message and icon
• The operation indicator lamp will flash

*

12 V DC supplied by an indoor unit
