Duct High Static Pressure ARXC060HTBH
Features
- Static Pressure Mode Selection
- Easy Installation (Compact & Lightweight)
- Automatic Airflow Adjustment Function
- Safety measures in Case of Refrigerant Leak
- High-Efficiency DC Fan Motor Achieves Low Energy Consumption
Capacity
18.0 kW
20.0 kW
Specifications
| Power Source | Phase | Single phase | |
|---|---|---|---|
| Voltage | 220 - 240 V | ||
| Frequency | 50 Hz | ||
| Capacity | Cooling | 18.0 kW | |
| Heating | 20.0 kW | ||
| Input Power | 494 W | ||
| Airflow Rate | Cooling | High | 3450 m³/h |
| Middle | 3010 m³/h | ||
| Low | 2480 m³/h | ||
| Heating | High | 3450 m³/h | |
| Middle | 3010 m³/h | ||
| Low | 2480 m³/h | ||
| Static Pressure Range | 0 to 260 Pa | ||
| Standard Static Pressure | 100 Pa | ||
| Sound Pressure Level*2 | Cooling | High | 47 dB(A) |
| Middle | 43 dB(A) | ||
| Low | 38 dB(A) | ||
| Heating | High | 47 dB(A) | |
| Middle | 43 dB(A) | ||
| Low | 38 dB(A) | ||
| Net Dimensions | Height | 425 mm | |
| Width | 1250 mm | ||
| Depth | 490 mm | ||
| Net Weight | 53.0 kg | ||
| Connection Pipe Diameter | Liquid (Flare) | φ9.52 mm | |
| Gas (Flare) | φ15.88 mm | ||
| Drain Hose Diameter | φ25(I.D.), φ32(O.D.) mm | ||
Scroll
Dimensions
Indoor Unit : ARXC060HTBH
